Bridges and marine structures endure extreme environmental conditions — constant moisture, saltwater exposure, UV radiation, and chemical attack. Traditional materials like steel and aluminum require frequent maintenance or coating renewal, which drives up long-term costs.
Fiber-Reinforced Polymer (FRP) structural profiles, produced by GTOFRP, have emerged as a durable alternative, combining high strength, lightweight design, and corrosion resistance. These qualities make FRP a preferred choice in bridges, ports, jetties, and coastal infrastructure, where longevity and performance are critical.
FRP structural profiles consist of continuous glass or carbon fibers embedded in a polymer matrix, typically vinyl ester or epoxy resin. The result is a composite material with high tensile strength, low density, and complete immunity to rust.
| Property | FRP Profiles | Steel | Aluminum |
|---|---|---|---|
| Corrosion Resistance | Excellent | Poor | Moderate |
| Density (g/cm³) | 1.9 | 7.8 | 2.7 |
| Thermal Conductivity | Low | High | High |
| Maintenance Requirement | Minimal | Frequent | Moderate |
| Service Life | 30–50 years | 15–25 years | 20–30 years |
In structural applications where salt spray, moisture, or chemical contact are unavoidable, FRP's non-corrosive nature provides unmatched longevity and cost savings.
GTOFRP designs and supplies pultruded FRP profiles that replace steel beams, gratings, and handrails in bridge and marine structures. Each product meets international standards (ASTM, ISO, and EN) for strength and stiffness.
FRP I-beams, channels, and box sections for load-bearing elements
FRP decking panels for bridge walkways and maintenance paths
FRP handrails and guardrails for safety and corrosion protection
FRP gratings for drainage and anti-slip surfaces
FRP rebar and connectors for structural reinforcement
You can view specifications and mechanical data on the FRP Bridge Components Page.
In 2019, GTOFRP supplied FRP structural profiles for a 60-meter pedestrian bridge spanning a coastal canal in Malaysia.
Project Highlights:
Weight reduction: 42% lighter than a comparable steel bridge
Installation time: Reduced by 30% due to modular FRP profiles
Maintenance: Zero corrosion after 5 years of continuous use
Design load: Compliant with AASHTO pedestrian bridge standards
Lightweight construction allows smaller foundations and faster assembly.
Corrosion-proof profiles require no repainting or galvanization.
Non-conductive materials improve safety near electrical systems.
UV-stable finishes maintain color and surface integrity for decades.
To see technical drawings and project data, visit GTOFRP's Bridge Application Center.
A marine port operator in the Netherlands replaced aging aluminum and steel walkways with GTOFRP pultruded profiles. The system has been in service since 2017.
Results after 7 years of operation:
No corrosion or structural degradation
Slip-resistant FRP grating remained intact
Structural deflection within designed limits
Maintenance cost reduction of 70%
Saltwater and chemical resistance: FRP remains stable in saline environments.
Low thermal expansion: Ensures stable geometry under temperature variation.
Non-magnetic properties: Ideal for marine radar and electronic zones.
Ease of repair: Damaged sections can be replaced modularly.
Visit the Marine Engineering Projects Page for technical data and case studies.
To validate performance, GTOFRP conducted accelerated corrosion and environmental exposure tests over 5,000 hours using ASTM B117 (Salt Fog Test).
| Test Parameter | FRP Profile Result | Steel (Galvanized) | Aluminum 6061 |
|---|---|---|---|
| Weight Loss (%) | <0.2 | 2.8 | 1.5 |
| Surface Degradation | None | Visible rust | Oxidation layer |
| Tensile Strength Retention | 98% | 82% | 87% |
| Color Fade (ΔE) | <1.0 | – | – |
The GTOFRP FRP profiles maintained mechanical properties and visual appearance, confirming long-term resistance to salt, moisture, and UV radiation — essential for coastal bridge and marine infrastructure.
Load Analysis: FRP has a high strength-to-weight ratio but lower modulus than steel; deflection control must be factored in.
Connection Design: Stainless steel fasteners and composite joints are commonly used.
Thermal Expansion: FRP expands less than aluminum but more than concrete; expansion joints should be integrated.
Fire Performance: GTOFRP offers fire-retardant resins (ASTM E84 Class 1) for enhanced safety in public structures.
For engineers developing new designs, refer to GTOFRP's Technical Design Manual for detailed formulas and load tables.
A full lifecycle study comparing FRP bridges vs. steel bridges found:
| Cost Component | FRP Bridge | Steel Bridge |
|---|---|---|
| Material | Moderate | Lower |
| Fabrication | Lower | Higher |
| Installation | Easier | Moderate |
| Maintenance (20 yrs) | Minimal | High |
| Total Cost | 20–30% less | — |
Beyond cost savings, GTOFRP's pultruded FRP systems offer sustainability advantages:
Zero VOC emissions during operation
Recyclable resin systems in new composite formulations
Reduced CO₂ footprint in manufacturing compared to metal structures
1. Coastal Pedestrian Bridge – Singapore (2020)
GTOFRP supplied FRP I-beams and handrails for a lightweight coastal bridge.
→ After 4 years, the structure shows no visible corrosion.
2. Offshore Jetty Platform – UAE (2021)
Pultruded FRP gratings replaced steel decking exposed to saline spray.
→ Load-bearing performance retained 100% of original design.
3. Fishing Harbor Walkway – Norway (2022)
Customized FRP channels and guardrails were used for low-temperature marine environments.
→ Thermal expansion performance remained within tolerance limits.
For more engineering references, visit GTOFRP's Project Gallery.
1. Why use FRP in bridges instead of steel?
FRP provides equal strength with much lower weight and complete corrosion resistance, eliminating repainting and rust control.
2. How long do FRP bridge structures last?
Properly designed FRP bridges have service lives exceeding 50 years, even in harsh marine climates.
3. Can FRP be used in vehicular bridges?
Yes. FRP decks and girders have been used in vehicular and pedestrian bridges globally with full compliance to AASHTO standards.
4. How does FRP perform under UV exposure?
GTOFRP applies UV-resistant gel coats to prevent fading and surface degradation over decades.
5. Can FRP structures handle high temperatures?
Yes, FRP maintains integrity up to 150°C; fire-retardant systems are available for special use.
6. Where can I request design support or material samples?
Visit GTOFRP's Contact Page to reach the engineering support team for project consultation.
Bridges and marine structures demand durable, maintenance-free materials that can withstand decades of environmental exposure.
GTOFRP's FRP structural profiles deliver exactly that — combining corrosion immunity, lightweight efficiency, and structural reliability backed by real-world data.
Engineers and project developers seeking high-performance materials can access full specifications, drawings, and testing results via the FRP Bridge and Marine Applications Page.
With proven performance in multiple global projects, GTOFRP continues to lead the transition from traditional metals to advanced composite structures.
